Standard base adjustable leveling feet with an integrated PA6 pad on the floor-contact surface combine height adjustment and dedicated scratch protection in one component. The PA6 pad provides the same floor-safe surface found on our furniture glides and furniture pads, built directly into the leveling foot base. No separate pad required. Static load capacity: 60 kg (M6 and 1/4″-20) to 80 kg (5/16″-18) per foot.
Not sure what size? See the size chart ↓
📦 Sold in packs of 4 — quantity adjustable at checkout
Standard leveling feet adjust height and contact the floor with a plain PA base. That PA base is adequate for most floors, but on hardwood, engineered wood, luxury vinyl, and other scratch-sensitive surfaces, PA under sustained load can cause micro-scratching over time. Adjustable leveling feet with pad solve this by integrating a PA6 floor protection pad directly into the base. The PA6 pad provides the same scratch-safe surface used in our furniture glides and furniture pads, permanently bonded to the leveling foot during manufacturing. Height adjustment and dedicated floor protection in one component.
Ø 38 mm PA base with integrated PA6 pad. Zinc-plated steel threaded rod. Available in M6 and two imperial thread sizes (5/16″-18 and 1/4″-20) for both metric and North American furniture specifications. Adjustable leveling feet with pad for furniture on scratch-sensitive floors. Rod length 25 mm. Black. Sold individually.
All three variations share the same Ø 38 mm base with integrated PA6 pad and 25 mm rod length. The only difference is the thread size. Choose the thread that matches the threaded insert in your furniture leg.
Metric thread for furniture with M6 threaded inserts. Static load capacity: 60 kg per foot. Compatible with M6 round, square, and rectangular threaded inserts. Black.
Imperial thread for North American furniture with 5/16″-18 threaded inserts. Static load capacity: 80 kg per foot. Common on domestically manufactured commercial furniture. Black.
Imperial thread for lighter North American furniture with 1/4″-20 threaded inserts. Static load capacity: 60 kg per foot. Common on residential and light commercial furniture. Black.
For standard base leveling feet without a pad in Ø 30 and 45 mm with M6 through M12 threads, see standard base adjustable leveling feet. For low-profile leveling feet with pad, see low-profile with pad. For a wider range of thread sizes and rod lengths without a pad, browse all adjustable leveling feet. For custom configurations, contact Business Solutions.
PA6 is the same material used across our furniture glides and furniture pads product lines. It is engineered specifically for floor contact: low friction, high wear resistance, and a smooth surface that does not scratch finished floors. On adjustable leveling feet with pad, the PA6 layer is permanently bonded to the bottom of the PA base during manufacturing.
PA (polyamide) is an excellent structural material for the leveling foot body. It handles compressive loads, resists chemicals, and maintains dimensional stability. But as a floor contact surface, PA has a higher coefficient of friction and a rougher micro-texture than PA6. Under the sustained compressive load of a leveling foot (the full weight of one furniture corner pressing continuously on the same spot), PA can micro-scratch sensitive finishes over months of contact. PA6 eliminates this risk. Leveling feet with floor protection pad that protect from the moment of installation.
The PA6 pad is integrated during manufacturing, not glued on afterward. This matters because leveling feet experience rotational force every time the height is adjusted (turning the foot rotates the base against the floor). An adhesive pad can shift, peel, or detach under this rotation. The permanently bonded PA6 pad cannot. It stays in place through every adjustment, every relocation, and every cleaning cycle. PA6 pad adjustable leveling feet that maintain floor protection for the life of the foot.
Adjustable leveling feet with pad are available in one metric thread (M6) and two imperial threads (5/16″-18 and 1/4″-20). This makes the product compatible with both European metric furniture and North American imperial furniture specifications.
Many furniture manufacturers in the US and Canada use imperial threaded inserts rather than metric. The 5/16″-18 thread is comparable in size to M8 and covers standard to heavy commercial furniture. The 1/4″-20 thread is comparable to M6 and covers lighter residential and commercial furniture. These imperial thread leveling feet screw directly into imperial threaded inserts without adapters, cross-threading, or compatibility issues.
The M6 thread covers the same lightweight to standard furniture range as M6 on other leveling feet in the catalog. Compatible with M6 threaded inserts in round (Ø 28 mm), square (20 × 20 mm), and other tube shapes. For heavier loads requiring M8, M10, or M12 without a pad, see standard base adjustable leveling feet.
Everything a standard leveling foot provides (height adjustment, wobble elimination, noise reduction) plus dedicated PA6 scratch protection on the floor contact surface. The National Wood Flooring Association (NWFA) recommends protective contact surfaces on all furniture legs, and adjustable leveling feet with pad meet that recommendation with a purpose-built PA6 floor contact layer.
The primary advantage over standard leveling feet. On hardwood, engineered wood, luxury vinyl plank, polished concrete, and sealed natural stone, the PA6 pad prevents the micro-scratching that accumulates under sustained static load. Every table, desk, and fixture rests its full weight on the leveling feet continuously. Over weeks and months, a plain PA base can leave marks. The PA6 pad does not. Leveling feet with built-in pad that protect finished floors from day one.
The threaded rod provides the same height adjustment as any leveling foot: turn to raise or lower each corner independently until the furniture sits level. The PA6 pad does not affect the adjustment mechanism. It adds floor protection to the adjustment function. Unlike leaving furniture on unprotected leveling feet, the integrated pad ensures the floor stays scratch-free while the furniture stays level. Adjustable feet with pad for furniture that needs both functions.
Without this product, achieving the same result requires a standard leveling foot plus a separate self-adhesive furniture pad applied to the base. That adhesive pad can shift, peel, or compress unevenly. It needs periodic replacement. Adjustable leveling feet with pad eliminate the separate pad entirely. One component. No adhesive. No maintenance. No peeling.
The PA6 pad adds a softer contact layer between the foot and the floor. On hard surfaces like tile, polished concrete, and hardwood, this reduces the contact noise when furniture shifts, vibrates, or is moved slightly. The noise reduction is cumulative across all feet on all furniture in a room. In restaurants, offices, and conference rooms, the quieter contact adds up.
Three materials in one component. The PA body provides structural support. The zinc-plated steel rod provides the threaded connection. The PA6 pad provides floor protection. Each material handles a specific function.
The Ø 38 mm PA base carries the compressive load from the furniture leg through the threaded connection to the floor. PA provides the rigidity and dimensional stability needed under sustained load. The 38 mm diameter positions this between the Ø 30 and Ø 45 mm standard bases, suitable for a broad range of furniture leg sizes.
Permanently bonded to the bottom of the PA base. PA6 has a lower coefficient of friction than PA, higher wear resistance, and a smoother micro-surface. The pad covers the full Ø 38 mm base diameter for edge-to-edge floor protection. The same PA6 compound used in furniture glides and furniture pads across the catalog.
25 mm rod length. Available in M6, 5/16″-18, and 1/4″-20 threads. Zinc plating provides adequate corrosion resistance for standard indoor use environments. The rod is permanently molded into the PA base body during manufacturing.
When do you need the integrated pad, and when is a standard leveling foot sufficient?
Standard base leveling feet have a plain PA base with no PA6 pad. They provide height adjustment and basic floor contact. On concrete, industrial flooring, and surfaces where scratching is not a concern, the standard version is sufficient. On hardwood, engineered wood, and luxury vinyl, the pad version provides dedicated scratch protection that the standard does not.
You can apply a separate self-adhesive furniture pad to any standard leveling foot base. This works but introduces an adhesive bond that can fail under the rotational and compressive forces of a leveling foot. The integrated PA6 pad on this product is permanently bonded during manufacturing and cannot shift or peel.
Low-profile with pad offers the same PA6 floor protection but on a shorter base (9 mm vs. the standard height). Choose low-profile when minimal foot visibility matters. Choose standard base with pad when the taller profile is acceptable and provides better stability.
Any furniture with threaded inserts that sits on a scratch-sensitive floor. The integrated PA6 pad means you do not need to add separate floor protection to the leveling feet.
The PA6 pad adds the most value on smooth, finished hard floors where micro-scratching is the primary concern. On other floor types, the benefit varies. This guide helps you decide whether adjustable leveling feet with pad are the right choice for your specific floor.
Solid hardwood floors (oak, maple, walnut, cherry). Engineered hardwood with finished veneer. Luxury vinyl plank (LVP) and luxury vinyl tile (LVT). Polished concrete with sealed finish. Sealed natural stone (marble, granite, travertine). Laminate flooring with wear layer. Cork flooring. Bamboo flooring. All of these surfaces can micro-scratch under sustained static load from a plain PA base. Adjustable leveling feet with pad prevent this damage on every contact point.
Raw concrete and unfinished surfaces: already rough, scratching is not a concern. Textured ceramic tile: the texture itself dominates the wear pattern. Carpet and soft flooring: no hard surface to scratch. Industrial epoxy: designed for heavy equipment, furniture scratching is not relevant. Outdoor pavers and decking: use standard leveling feet or stainless steel rod versions for corrosion resistance. Rubber gym flooring: soft surface absorbs contact.
For furniture manufacturers and facility managers ordering adjustable leveling feet with pad for new furniture projects, here is the specification process:
Specify adjustable leveling feet with pad at the design stage. Choose the thread to match the threaded insert you are installing in the tube leg. For metric manufacturing, specify M6. For North American imperial manufacturing, specify 5/16″-18 or 1/4″-20. The 25 mm rod length provides standard adjustment range for typical commercial and residential floors. If your production needs different rod lengths or additional thread sizes with the integrated PA6 pad, contact Business Solutions for custom configurations.
If your existing furniture already has threaded inserts with M6, 5/16″-18, or 1/4″-20 threads, adjustable leveling feet with pad can replace the current leveling feet without any modification to the furniture. Unscrew the old foot, screw in the new foot with pad. The PA6 pad adds floor protection to furniture that was not originally specified with it. For existing furniture with other thread sizes, apply a separate self-adhesive pad to the current leveling foot base instead.
Anywhere furniture with threaded inserts needs both height adjustment and guaranteed floor protection on scratch-sensitive surfaces.
Restaurant dining tables on hardwood floors, hotel lobby tables on polished stone, office desks on luxury vinyl, and conference tables on engineered wood. In these environments, floor damage is costly and visible. Facility managers increasingly require furniture with built-in floor protection as a condition of the furniture specification. Adjustable leveling feet with pad meet this requirement without separate pads that need monitoring and replacement. When a restaurant chain specifies adjustable leveling feet with pad across all locations, every table arrives ready for scratch-sensitive floors without additional accessories or assembly steps. Available for bulk orders. For commercial pricing, visit Business Solutions.
Dining tables on hardwood floors in homes, display tables in retail stores with premium flooring, and any residential furniture where the homeowner wants both leveling and floor protection. The imperial thread options (5/16″-18 and 1/4″-20) make adjustable leveling feet with pad particularly relevant for North American residential furniture that uses imperial threaded inserts. The integrated pad eliminates the need to remember to apply and maintain separate adhesive pads on each foot. For homeowners who have invested in high-quality hardwood or engineered flooring, the PA6 pad provides peace of mind that the furniture is not silently damaging the floor underneath.
Check periodically that the leveling foot is tight in the threaded insert and the furniture remains level. Inspect the PA6 pad surface for wear, particularly on furniture that gets moved or adjusted frequently. The PA6 pad is highly wear-resistant but will eventually show contact marks under heavy use. On commercial furniture in high-traffic environments, inspect every 6 to 12 months. The pad surface can be wiped clean with a damp cloth. If the PA6 shows visible wear-through to the PA body beneath, replace the leveling foot.
On furniture that gets relocated between rooms or buildings, the PA6 pad may pick up grit from the floor during the move. Before setting the furniture in its new position, wipe the pad surface clean to prevent trapped grit from scratching the new floor location. This is especially important when moving furniture from a rough or dirty surface to a finished hardwood or luxury vinyl floor. Adjustable leveling feet with pad protect the floor only when the pad surface itself is clean.
Standard Base: Ø 30 and 45 mm, M6 to M12, 10 to 110 mm rods. No pad.
Low-Profile: 9 mm base height, M4 to M10.
Round Self-Adhesive Furniture Pads: PA6 pads for any surface.
Round Self-Adhesive Furniture Glides: PA6 on ABS platform.
| Specification | Details |
|---|---|
Product Type |
Adjustable Leveling Feet – Type A (with Pad) |
Materials |
PA (Polyamide) base + PA6 (Polyamide 6) pad + Fe HDG steel stem |
Fit Style |
Threaded stem with fixed base |
Floor Compatibility |
All hard flooring |
Furniture Compatibility |
Storage units, shelving, desks, tables, compact fixtures, etc |
Leg Compatibility |
Metal threaded inserts |
Tube/Foot Diameters |
Ø45 mm (1.77") |
Thread Sizes |
M6 (6 mm), 1/4"-20, 5/16"-18 |
Thread Lengths |
19 mm (0.75") |
Weight Capacity |
60-80 kg (132-176 lbs) static load per foot |
Color Options |
Black |
Installation Type |
Screw-in by hand or wrench |
Key Benefits |
Compact design, floor-safe pad, adjustable support, quick install |
Indoor/Outdoor Use |
Indoor | Covered Outdoor | Uncovered Outdoor |
| Base Diameter (Ø) | Thread Size (M) | Threaded Stem Length (L) | Base Height (H) | Static Load Capacity (SL) |
|---|---|---|---|---|
45 mm (1.77") |
M6 (6 mm) |
19 mm (0.75") |
11 mm (0.43") |
60 kg (132 lbs) |
45 mm (1.77") |
5/16"-18 |
19 mm (0.75") |
11 mm (0.43") |
80 kg (176 lbs) |
45 mm (1.77") |
1/4"-20 |
19 mm (0.75") |
11 mm (0.43") |
60 kg (132 lbs) |
PA is a strong structural material, but PA6 is engineered specifically for floor contact. PA6 has a lower coefficient of friction, higher scratch resistance, and a smoother surface that protects finished floors better than PA alone. On hardwood, engineered wood, and luxury vinyl, the PA6 pad prevents the micro-scratching that a plain PA base can cause under sustained load. The pad is permanently bonded to the base, so it cannot shift or peel off like an adhesive pad applied after the fact.
Many North American furniture manufacturers use imperial threaded inserts (5/16″-18 and 1/4″-20) rather than metric. These inch thread options allow the leveling foot to screw directly into imperial threaded inserts without adapters. The 5/16″-18 supports 80 kg per foot. The 1/4″-20 supports 60 kg per foot. The M6 option serves metric specifications at 60 kg per foot. Choose the thread that matches your threaded insert.
No. The PA6 pad is permanently integrated into the base during manufacturing. If the pad wears through, replace the entire leveling foot. The PA6 material is highly wear-resistant and lasts through the normal service life of the furniture under standard use conditions.
The PA6 pad is designed for smooth hard floors (hardwood, engineered wood, luxury vinyl, polished concrete, smooth tile). On rough or textured surfaces, the pad provides less benefit because the texture itself causes wear regardless of the contact material. For rough surfaces, standard base leveling feet without pad are adequate since the floor texture makes scratch protection less relevant.
The integrated pad is permanently bonded during manufacturing, so it cannot shift, peel, or fall off. A separate self-adhesive furniture pad applied to a standard leveling foot base can lose adhesion over time, especially under the compressive and rotational forces of a leveling foot. The built-in pad eliminates that failure mode.
